The aluminum checker plate transporter floor for the VW Crafter L4 from 2017 onwards was specially developed for large-volume panel vans with a high payload. Especially for vehicles in this class, which are in constant commercial use, a resilient and precisely fitting cargo area floor is crucial for safety, durability, and maintaining the value of the vehicle.
Aluminum checker plate transporter floor for VW Crafter – L4 from 2017
The precision CNC-machined transporter floor for VW Crafter L4 is tailored exactly to the contours of the cargo area. It is suitable for vehicles with front-wheel drive, rear-wheel drive, and all-wheel drive. The combination of sturdy birch plywood and a 1.5–2.0 mm thick aluminum checker plate surface ensures a non-slip and extremely durable loading area.
Suitable for the L4 wheelbase with the following vehicle dimensions:
📏 Vehicle dimensions – VW Crafter L4 from 2017
| Designation |
Drive type |
Wheelbase |
Total vehicle length |
Vehicle height |
Cargo space length |
| L4H3 |
FWD / RWD / AWD |
4,490 mm |
6,836 mm |
2,590 – 2,625 mm |
4,300 mm |
Note: The total vehicle length can be found in the vehicle registration document under item 18, the vehicle height under item 20, and the year of manufacture under item 6 (information for German registration certificates).
The floor panel is supplied in several parts. This facilitates installation in long cargo areas and enables precise adaptation to the vehicle geometry of the VW Crafter L4.
Material structure of the aluminum checker plate floor panel
The transporter floor is available in either 9 mm or 12 mm thickness. The substrate is a phenolic resin-bonded screen-printed floor made of birch plywood in accordance with EN 312-2 / Class 3, which is specially designed for use in commercial vehicles.
The applied aluminum checker plate layer in quintet design increases slip resistance and ensures a permanently resilient surface. This makes the floor ideal for transporting heavy tools, machines, or palletized goods.
Installation and secure fastening
The floor is laid from front to rear in the cargo area. The individual panel segments are screwed together and, once installed, form a stable, level loading area. The screw connections are virtually invisible after installation and do not interfere with everyday work.
The lashing recesses included in the scope of delivery are inserted into the designated recesses and secured with the original lashing eyes of the VW Crafter. For wide vehicle variants, a light adhesive can be used between the body and the floor panel to minimize vibrations.
Airline rails for flexible load securing
Optionally, airline rails can be integrated transversely to the direction of travel under the roof rails. The floor panel is milled to fit precisely and the rails are permanently glued in place.
The airline rails are each 1.20 m long and are ideal for securing loads with locking bars. Please note that airline rails can only be integrated with 9 mm thick floor panels. Different lengths or positions are available on request.
Features of the van floor
– 9 mm or 12 mm thick birch plywood
– 1.5–2.0 mm aluminum checker plate surface
– Oil, water, and wear-resistant melamine coating
– UV-resistant and
lightfast
– CNC-manufactured and precisely fitted for VW Crafter L4
Note: Not suitable for station wagons with seat rails or double cabs. For use exclusively with VW Crafter panel vans.
